Automatic Height Control Valve

Type	LEVELLING VALVE
Place of Origin	Zhejiang, China
Purpose	For replace/repair
OE NO.	2506169C91 KD2360 HAD500NS EM37260
Application	AIR SUSPENSION SYSTEM
Single Box Gross Weight	0.574 KGS
Single Box Net Weight	0.490 KGS
Single Box Size	24 CM*9.5 CM*8.5 CM





2506169C91 Automatic Height Control Valve belongs to LEVELLING VALVE.



Structural Composition

·Valve Assembly

  -Dual-chamber pneumatic structure

  -Low-inertia balancing spool

  -Anti-jamming guidance mechanism

·Sensing & Adjustment Module

  -Magnetoresistive non-contact sensing

  -Temperature-adaptive compensation unit

  -Modular signal processor

·Connection System

  -Rotary-sealed pneumatic interface

  -EMI-resistant composite wiring harness

  -Anti-loosening snap-on base



Core Functions

·Dynamic Height Management

  -Multi-axis load independent compensation

  -Transient impact damping control

  -Automatic slope posture correction

·Smart Diagnostics

  -Self-monitoring wear detection

  -Airway blockage pre-warning

  -Electrical fault code generation



Performance Features

·Sub-millisecond response latency

·Fully-sealed contamination-proof design

·Reverse-pulse self-cleaning function

·Brushless motor-driven adjustment



Installation & Maintenance

·Requires dynamic balancing calibrator

·Chemical solvent cleaning prohibited

·Bearing lubrication every 2,000 operating hours





2506169C91 Automatic Height Control Valve belongs to AIR SUSPENSION SYSTEM.



System Classification

·Component Type: Height Control Valve

·Application System: Air Suspension System



Connection Specifications

·All Ports: 1/4" Tube (Standard Push-to-Connect)



Key Features

·Unified Connection System

  -All pneumatic ports use 1/4" tube fittings

  -Simplified installation with consistent sizing

·Reliable Sealing Performance

  -Positive-locking tube connectors

  -Vibration-resistant retention

·Maintenance Advantages

  -Quick-disconnect capability

  -Universal tubing compatibility

  -Reduced spare parts inventory





























Q: Could you provide the size specifications of your manufacturing facility?

A: Our production premises span more than 3000 square meters.



Q: What is the smallest production run your facility accepts?

A: The standard production batch starts at 50 pieces, though we're happy to discuss flexible arrangements based on specific requirements.



Q：How do you control product quality?

A：

1) Batch-specific documentation including production schedules and process checklists.

2) Three-tier quality verification system covering initial, interim, and pre-shipment inspections.



Q: Could you advise on production lead times?

A: Lead times vary between 48 hours to 28 calendar days, contingent upon order volume and product specifications.



Q: Do you support custom manufacturing solutions?

A: We specialize in both OEM and ODM services, offering tailored product development to meet specific client requirements.
